HOME/PRODUCTS/RENEWABLE ENERGY/SOLAR SYSTEMS/Portable Hybrid Solar Energy Storage System
Portable Hybrid Solar Energy Storage System — AXION by Arab Tower
AXION by Arab TowerSolar Systems

Portable Hybrid Solar Energy Storage System

MPSG-E Series · 1kW to 6.2kW

All-in-One Portable System — built-in LiFePO4 battery, MPPT controller and pure sine wave inverter in a single wheeled unit

Power Range
1–6.2 kW
Max Battery Storage
4.8 kWh
Max PV Voltage
450 V
Max Charge Current
120 A
Technical Specification

Key Features

  • All-in-One Portable System — built-in LiFePO4 battery, MPPT controller and pure sine wave inverter in a single wheeled unit
  • Standing Wheel Design — caster-mounted chassis for easy repositioning across field sites, events and emergency locations
  • Built-in MPPT Solar Controller — up to 120A charge current, wide PV input range up to 450VDC
  • LiFePO4 Battery Storage — 1,280Wh to 4,800Wh built-in capacity with overcharge and overdischarge protection
  • RGB Status Indicator — colour-coded operating mode display for mains, energy-saving and battery modes

Technical Specifications

ParameterSpecification
Output Voltage195.5–253VAC
Output WaveformPure Sine Wave
Input Voltage220/230/240VAC
Input Frequency50/60Hz
Battery ChemistryLiFePO4 (built-in)
DisplayDigital LCD
AC ChargingYes

Model Range

SpecificationMPSG-E1000MPSG-E3600MPSG-E6200
Rated Power1,000W3,600W6,200W
Battery Voltage12.8V25.6V48V
Built-in Battery1,280Wh2,560Wh4,800Wh
Max PV Power550W6,200W6,500W
PV Charge Range20–150VDC60–450VDC60–450VDC
Charge Current80A120A120A

Specify the Portable Hybrid Solar Energy Storage System for your project

AXION solar & storage, supplied and engineered into your system by Arab Tower — across the UAE and internationally.
